Pickit processor 3.0-a

The Pickit processor 3.0-a is a light and compact unit that fits in a 1U rack mount. Its 12V DC-in power supply is a separate adapter, so it can be optionally mounted on an Autonomous Ground Vehicle (AGV).

../../../_images/processor-three-a.jpg

Processor ports

The front side of the processor has:

  • 1x power switch. Press once to turn on, press once again to turn off.

  • 1x audio jack for a remote power switch.

  • 2x LED indicators (power and HDD).

../../../_images/processor-three-a-front.jpg

The back side of the processor has:

  • 3x RJ-45 ports labeled “Your_PC”, “Robot”, and “LAN”. This article gives the description on how to configure the network settings of your Pickit system.

  • 4x USB ports that can be used to connect Pickit cameras.

  • 1x lock type DC power jack port.

../../../_images/processor-three-a-back.jpg

Power input and installation

Apart from the provided power supply, the processor is also compatible with the following options:

  • DIN-Rail power supplies such as this one, for convenient mounting in control panels or electrical cabinets.

  • Direct 12V DC input, so it can be mounted on an Autonomous Ground Vehicle (AGV).

The processor comes with two sets of brackets offering the possibility to installing it on a wall (below left) or mount it in a rack (1U high, below right). The necessary screws are also included.

../../../_images/processor-three-a-mounting.jpg

The power supply connects to the “DC IN” port on the back side of the processor.

../../../_images/connect-power-cable.png

Note

In case of a power failure while the processor is on, it will restart automatically when power is restored. Pickit will start with robot mode enabled, that is, ready to receive robot commands.

Technical specifications

You can download a CAD file of the Pickit processor 3.0 from the CAD resources page.

  • Processor: 6 cores (12 threads) at 3.2 Ghz

  • 19-inch server: rack compatible (1U)

  • Dimensions (W x H x D): 250 x 44.2 x 225 mm (9.84” x 1.74” x 8.85”)

  • Weight: 2.5 Kg

  • Operating temperature: 0 °C to 50 °C

  • Non-operating temperature: -40 °C to 85 °C

  • Vibrations (5-500Hz): 1 Grms (HDDx1); 3 Grms (SSD x 1)

  • IP rating: IP20

  • Humidity: ̃10% to 85% @ 40°C (non-condensing)

  • Input Voltage power: 12 V DC

  • Input Current: 10 A

  • Power adapter specifications:

    • Input voltage: 100 - 240 V AC

    • Input current: 2.0 A AC

    • Input frequency: 50 - 60 Hz

Power consumption

  • While turned off: 3 W

  • Booting: 35 W

  • Idle: up ot 40 W

  • Heavy processing: up to 90 W
